There is a moment every Tacoma owner knows. You are parked at the trailhead, coffee going cold in the cupholder, watching a built-out rig crawl up the obstacle you have been eyeing for months. Its bumpers shrug off rock. A spare tire swings out of the way like it was choreographed. There is a tent folded neatly on the bed rack and a fuel can riding shotgun on a Molle panel. Meanwhile your stock third-gen Taco sits there honest and capable, but soft around the edges, like it showed up to a fight in a polo shirt.
That was the starting point for this build. One weekend overlander, a 2016-2023 Tacoma, and a plan to turn a great daily driver into something that could actually earn its keep on the trail. The good news: Body Armor 4x4 has assembled a Toyota bundle that takes the guesswork out of it. Every piece is engineered for the same truck, finished in the same two-stage textured black powder coat, and backed by the same 3-year finish and limited lifetime warranty. You are not stitching together mismatched parts from five vendors. You are building one cohesive rig.
Quick Answer
For a 2016-2023 Tacoma, the Body Armor 4x4 Toyota bundle covers the four upgrades that matter most: a stubby HiLine front winch bumper with high-clearance wings, frame-mounted Revo rock sliders, a modular Pro Series II rear bumper with swingouts and a 35-inch tire carrier, and an 800 lb static rated overland bed rack with bed Molle panels. Everything is bolt-on, color-matched, and built to grow in stages.
The Front End: Protection That Earns Its Approach Angle
The first upgrade is always the one that scares you the least and helps the most. Stock Tacoma front bumpers are mostly plastic and good intentions. They hang low, they crumple, and they leave your radiator and steering exposed to whatever the trail throws up.
The HiLine Front Winch Bumper (TC-19339) fixes all of that and adds a few tricks. It is a stubby, low-profile design, which is the entire point. By trimming back the bulky factory overhang, it dramatically improves your approach angle so you can nose up to a ledge instead of plowing into it. A welded bull bar adds protection out front, and there is a cutout for a 20-inch dual-row LED light bar for when the sun quits before you do. It is rated for up to a 10,000 lb winch, including Warn Zeon models, so the day you find yourself nose-deep in a mud hole, you have a way out that does not involve a phone call and a prayer. Integrated shackle recovery points mean your D-rings have a real home, and it still plays nice with the factory TRD skid plate.
Priced at $700, it is the foundation of the front end. To finish the look and the function, the build adds the HiLine High Clearance Side Wings (TC-19339W) for $300. Cut from 3/16-inch steel plate, the wings wrap the corners for added protection while keeping a compact profile that clears bigger tires. They also include provisions for a 6-inch single-row LED bar on each side, which is a tidy alternative to bolting on a separate set of ditch lights. Stubby bumper, big clearance, real recovery points. The front of the truck is no longer the weak link.
The Rocker Panels: Where Sliders Save the Day
If the front bumper is the upgrade that helps the most, rock sliders are the one you will be most grateful for and least likely to brag about. Nobody posts photos of the rock they did not hit. But the first time you hear steel kiss granite instead of crunching your rocker panel, you understand the value instantly.
The Revo Rock Sliders (TC-4125) are built from 1.75-inch tubing with a .120-inch wall and a 25-degree kickout. That angle is the clever bit. It pushes the slider out to shield the body from rocks and ruts, while staying tucked enough that you do not snag on every obstacle you slide past. They are 100 percent frame mounted using the factory hole locations, so there is no drilling, and they install in moments using points the truck already gave you.
Here is the part overlanders love: the sliders double as strong anchor points, rated to be lifted with a Hi-Lift jack at any point along their length. So when you put a wheel in a hole out where there is no cell signal, your recovery gear has somewhere solid to push against. At $800, they protect the most expensive sheet metal on the truck and quietly expand what you are willing to attempt. Fits the Double Cab Short Bed and Access Cab Long Bed with the 5-foot bed.
The Rear End: A Modular System That Grows With You
This is where the build stops being a collection of armor and starts being a platform. The Pro Series II Rear Bumper (TC-2966) is the centerpiece, and at $1,000 it is the biggest single investment in the bundle. It is worth understanding why.
Most rear bumpers protect and look mean and stop there. This one is modular by design. Out of the box it is a high-strength steel bumper with integrated shackle recovery mounts, fitment for two LED pods or flush-mount lights, OE receiver compatibility, and sensor compatibility so your parking aids keep working. It bolts on with no drilling in about an hour, and it follows the factory body lines so it looks like Toyota should have built it this way.
But the real story is what you can hang off it. The bumper accepts one or two accessory swingouts, and this build runs both. The Driver Side Swingout (TC-2966DS) and the Passenger Side Swingout (TC-2966PS) run $700 each and turn the back of the truck into adaptable storage. Each is rated up to 130 lbs and pre-drilled for mounting flexibility, so you can carry a spare tire, jerry cans, traction boards, a Rotopax, a Hi-Lift jack, or storage cases, whatever your trip demands. They swing on serviceable bearings with a robust compression latch and locking pin, plus a brushed aluminum knurled stopper that keeps the arm from over-extending. Each one even has a built-in foldable table, which sounds like a gimmick until the first time you are making coffee at camp and realize you have a clean, flat surface that was not there before.
To carry the spare, the build adds the Pro Series II Tire Carrier with License Plate Holder (TY-2966) for $259. It holds up to a 130 lb or 35-inch wheel and tire, and it bundles in the license plate holder and a rear camera relocation bracket so your backup camera and your plate both stay legal and functional. Getting that full-size spare off the bed and onto a swingout frees up the cargo space you are about to need.
Together, the rear bumper and dual swingouts and tire carrier are the difference between a truck that looks ready and a truck that is ready. Lock the arms for the highway, swing them open at camp, and reconfigure the load for every trip.
The Bed: Turning Cargo Space Into Camp
A spare tire on the swingout means the bed is finally free to do bed things. This is where overlanding stops being a day trip and starts being a basecamp.
The Tacoma Overland Rack (TC-6125) is the big enabler at $1,392. It bolts on using factory mounts, allows you to keep using the factory bed rails, and carries serious weight: an 800 lb static capacity and a 350 lb dynamic capacity. The static number is the one that matters at camp, because it means the rack will happily hold a rooftop tent with you and a friend inside it. The mounts fit most universal rooftop tents, and two included accessory mounts give you room for the rest of your kit. Sleep up top, keep the bed below for gear, and suddenly a Friday-after-work departure turns into a real weekend.
For the small stuff that always ends up rolling around the footwell, the build adds Molle to the bed walls. The Bed Side Molle System (TC-7125) is $200 per side and mounts behind the utility rail, so it works with most accessories and tonneau covers. The Front Bed Molle System (TC-7126) adds another $255 of organized real estate up against the cab. Both are formed from 3mm steel and include Hi-Lift mounting hardware, and both are happy to carry Rotopax containers, quick-fist mounts, Molle bags, and that Hi-Lift jack you finally have a clean place to stow. Recovery gear within reach, fuel and water secured, nothing sliding around on the washboard. That is the quiet luxury of a well-sorted bed.
The Full Bundle, By the Numbers
Body Armor 4x4 Tacoma Bundle Pricing
Pricing reflects Body Armor 4x4 listings at the time of writing. Confirm fitment for your cab and bed before ordering.
| Component | Part Number | Price |
|---|---|---|
| HiLine Front Winch Bumper | TC-19339 | $700 |
| HiLine High Clearance Side Wings | TC-19339W | $300 |
| Revo Rock Sliders | TC-4125 | $800 |
| Pro Series II Rear Bumper | TC-2966 | $1,000 |
| Driver Side Swingout | TC-2966DS | $700 |
| Passenger Side Swingout | TC-2966PS | $700 |
| Tire Carrier with License Plate Holder | TY-2966 | $259 |
| Tacoma Overland Bed Rack | TC-6125 | $1,392 |
| Bed Side Molle System (per side) | TC-7125 | $200 |
| Front Bed Molle System | TC-7126 | $255 |
Why the Bundle Beats Piecing It Together
You could chase each of these parts down individually. Plenty of people do, and they spend months cross-referencing fitment, matching finishes that never quite match, and discovering that the slider they bought does not clear the bumper they already installed.
The Body Armor 4x4 Toyota bundle sidesteps all of that. Every piece in this build is engineered for the 2016-2023 Tacoma, wears the same two-stage light-texture black powder coat, and installs with bolt-on, no-drill or minimal-trim hardware that most owners can handle in a driveway with light to moderate mechanical skill. The front bumper goes on in about two hours, the rear bumper in about one, the sliders in moments. Everything carries the same 3-year finish and limited lifetime warranty, so one truck, one look, one promise.
More than that, the system is designed to be built in stages. Start with the sliders and front bumper to protect the truck. Add the Pro Series II rear bumper when you are ready, then bolt on swingouts and a tire carrier as your trips get longer. Top it with the overland rack and Molle panels the season you decide to start sleeping out there. The bumper was built to accept the swingouts later. The bed was built to take the rack later. Nothing you buy first locks you out of what you buy next.
Suggested Build Order
Stage 1: Rock sliders and front winch bumper. Stage 2: Pro Series II rear bumper. Stage 3: Swingouts and tire carrier. Stage 4: Overland bed rack and Molle panels. Each stage stands on its own and sets up the next one without rework.
The Payoff
A few months after that morning at the trailhead, the same overlander is back. Different truck now, or rather the same truck wearing the work. The front end shrugs off a rock garden that would have scraped the old plastic bumper into the dirt. The sliders take a hit on a tight switchback and the rockers stay perfect. At camp the spare swings out of the way, the tent goes up on the rack, the foldable table holds dinner, and the fuel can sits exactly where it belongs.
That is what a real bundle buys you. Not just armor, but capability that compounds, a truck you trust further every time you point it down a trail. The 2016-2023 Tacoma was always a great place to start. The Body Armor 4x4 Toyota bundle is how you finish the job.
Ready to build yours? Explore the full Toyota bundle lineup and start with the piece that fits your next adventure.
